Gerber 3M™ Adhesive Transfer Tape 468MP
Adhesive Transfer Tape 468MP 12” wide 60 yards P83177A
These adhesives complement our LexEdge and Static Cling applications. The laminating adhesives provide the finish step in the production of decals.
3M 468MP Adhesive Transfer Tape is for long-term bonding of graphic nameplates, overlays (i.e. subsurface printed Lexan), rating plates, membrane switches, etc. to metal and high surface energy plastics in the aerospace, medical and industrial equipment, automotive, appliance and electronic markets. When bonding a thin, smooth, flexible material to a smooth surface, use 467MP with a 2.3 mil adhesive; use 468MP, with 5.2 mil of adhesive, when a texture is visible on one or both surfaces.
DESCRIPTION
Adhesive Transfer Tape 467MP and 468MP are popular choices for graphic attachment and
membrane switch applications because they have excellent quality, consistency and durability.
These products offer the following excellent performance characteristics: Clarity (virtually free of
vapor inclusions that are commonly found in adhesives produced by the traditional solvent
coating technique); Excellent high temperature performance as well as excellent shear strength
(that minimizes edge lifting and slippage of parts); Excellent resistance to harsh environments:
the adhesive can withstand splashes of organic solvents, weak acids and bases and salt water,
cleaning solutions, germicidals, disinfectants, oils, etc.
In addition, these perform well after exposure to humidity and hot/cold cycles and provides
some initial repositionability when bonding to plastic parts (not metal) which allows graphic parts
to be lifted and repositioned if initial alignment is incorrect.
INTENDED APPLICATIONS
Application to high surface energy substrates (HSE). On an HSE substrate, adhesive spreads
out to “wet” the surface to be bonded. The higher the surface energy, the better the bond
performance. Most popular applications are for appliance, transportation and automotive,
electronics and general industrial for name plates, graphic overlaps:
Long term bonding of graphic nameplates and overlays (“subsurface” printed
polycarbonate or polyester) to metal and high surface energy plastics in the aerospace,
medical and industrial equipment, automotive, appliance and electronic markets.
Bonding metal nameplates and rating plates in the aerospace, medical and industrial
equipment, automotive, appliance and electronic markets.
Bonding graphic overlays for membrane switches and for bonding the complete switch to
the equipment surface.
Page 2 of 6
High speed processing of parts in the medical, telecommunications and electronics
markets (medical components, durable labels, flexible circuits).
Lamination to industrial foams for rotary die-cutting of small gaskets for industrial and
electronics markets.
APPLICATION TECHNIQUES
For maximum bond strength (during installation of the final part) the surface should be
thoroughly cleaned and dried. Typical cleaning solvents are heptane* (for oily surfaces) or
isopropyl alcohol for plastics. Use reagent grade solvents since common household materials
like rubbing alcohol frequently contain oils to minimize the drying affect on skin and can interfere
with the performance of a pressure-sensitive adhesive.
Note: Carefully read and follow the manufacturer’s precautions and directions for use when
working with solvents. These cleaning recommendations may not be in compliance with the
rules of certain air quality management districts in California; consult applicable rules
before use.
It is necessary to provide pressure during lamination (1.5-20 pli recommended) and during final
part installation (10-15 psi) to allow the adhesive to come into direct contact with the substrate.
Using a hard edged plastic tool, which is the full width of the laminated part, helps to provide the
necessary pressure at the point of lamination. Heat can increase bond strength when bonding to
metal parts (generally this same increase is observed at room temperature over longer times,
weeks). For plastic parts, the bond strength is not enhanced with the addition of heat.
The ideal adhesive application temperature range is 60°F (15.6°C) to 100°F (38°C). Application
is not recommended if the surface temperature is below 50°F (10°C) because the adhesive
becomes too firm to adhere readily. Once properly applied, at the recommended application
temperature, low temperature holding is generally satisfactory.
When bonding a thin, smooth, flexible material to a smooth surface, it is generally acceptable to
use 3M 467MP. If a texture is visible on one or both surfaces, the 3M 468MP would be
suggested. If both materials are rigid, it may be necessary to use a thicker adhesive to
successfully bond the components.
PRODUCT CONSTRUCTION
Product
Number
Adhesive
Type/Color1
Adhesive
Thickness2
(mils, mm)
Liner
Color, Type, Print
Liner
Caliper / Liner Release3
3M Adhesive
Transfer Tape
467MP
200MP/Clear 2.3 mils
(0.06 mm)
Tan, 58#, Polycoated
Kraft, “3M 467MP
200MP Adhesive”
4.2 mils
50 grams/inch
3M Adhesive
Transfer Tape
468MP
200MP/Clear 5.2 mils
(0.13 mm)
Tan, 58#, Polycoated
Kraft, “3M 468MP
200MP Adhesive”
4.2 mils
50 grams/inch
Page 3 of 6
1
The adhesive color is transparent with a very slight yellow cast. The yellow cast is not typically visible in a single adhesive layer.
2
The thickness listed is based on a calculation from manufacturing controlled adhesive coat weights using a density of 1.012 g/cc.
3
Typical liner release value, in grams/inch, tested at 90 ipm.
PHYSICAL PROPERTIES & PERFORMANCE CHARACTERISTICS
Note: The following technical information and data should be considered representative or typical only and
should not be used for specification purposes.
I. Adhesion to Stainless Steel
ASTM D3330 modified (90° peel, 2-mil aluminum foil backing)
Dwell
467 MP
2 mil (0.002 inches)
468 MP
5 mil (0.005 inches)
ounces/inch N/100mm ounces/inch N/100mm
15 minute room temperature (RT) 47 51 66 72
72 hour RT 82 90 118 129
72 hour 158°F (70°C) 168 184 181 198
72 hour RT – 180° peel, 2 mil al foil 77 84 133 146
II. Adhesion to Other Surfaces
ASTM D3330 modified (90° peel, 2-mil aluminum foil backing)
Dwell
467 MP
2 mil (0.002 inches)
468 MP
5 mil (0.005 inches)
ounces/inch N/100mm ounces/inch N/100mm
72 hour RT aluminum 77 84 115 126
72 hour RT ABS 62 68 68 74
72 hour RT acrylic 61 67 67 73
72 hour RT glass 80 88 92 101
72 hour RT polycarbonate 58 63 65 71
72 hour RT rigid PVC (unplasticized) 52 57 69 76
III. Relative High Temperature Operating Ranges
Short term (minutes/hours) 400°F (204°C)
Long term (days/weeks) 300°F (149°C)
IV. Low Temperature Performance
The glass transition temperature for 467MP and 468MP is -31°F (-35°C). Many applications
survive below this temperature (factors affecting successful applications include: materials
being bonded, dwell at RT before cold exposure and stress below the TG [i.e. expansion/
contraction stresses, impact]). Optimum conditions are: bonding high surface energy
Page 4 of 6
materials, longer time at RT before cold exposure and little or no stress below the Tg. The
lowest service temperature is -40°F (-40°C).
Note: 467MP and 468MP are not recommended for low energy plastics (polypropylene,
polyethylene, powder coated paints).
V. Static Shear
ASTM D3654 – 1″ x 1″ sample area – aluminum foil to stainless steel
Temperature Load
Minutes to Failure
467 MP
2 mil (0.002 inches)
468 MP
5 mil (0.005 inches)
70°F (21°C) 2000 grams 10,000+ 10,000+
200°F (93°C) 1000 grams 10,000+ 10,000+
350°F (177°C) 500 grams 10,000+ 10,000+
450°F (232°C) 400 grams 60 75
450°F (232°C) 200 grams 10,000+ 10,000+
VI. Adhesion Retention after Immersion and Exposure (percent retention)
Control is 24 hour RT dwell on stainless steel, 2 mil al foil backing, 90° peel, 12 ipm
Test 467 MP
2 mil (0.002 inches)
468 MP
5 mil (0.005 inches)
Control adhesion value in ounces/inch 101 oz./inch 149 oz./inch
Gasoline – 1 hour RT immersion 89% 83%
MEK – 1 hour RT immersion 64% 66%
Weak acid – 4 hour RT immersion 86% 86%
Weak base – 4 hour RT immersion 84% 83%
Oil (10W30) – 72 hour, 120°F (49°C) immersion 146% 141%
Water – 100 hours, 70°F (21°C) 105% 116%
Salt water (5%) – 72 hours, 70°F (21°C) 105% 93%
Warm/humid – 7 days, 90°F (32°C) and 90%
relative humidity 131% 101%
UV cabinet – 30 days, 70°F (21°C) 147% 93%
Temperature cycle – Three cycles* 148% 158%
*One cycle is 4 hours, 158°F (70°C); 4 hours, -20°F (-29°C); 16 hours, 70°F (21°C)
Page 5 of 6
ELECTRICAL, MECHANICAL AND THERMAL PROPERTIES
Note: The following technical information and data should be considered representative or typical only and
should not be used for specification purposes.
Property 467 MP
2 mil (0.002 inches)
468 MP
5 mil (0.005 inches)
Insulation Resistance (test voltage = 100
VDC)
Mil-I-46058C
>1 x 1010 ohms >1 x 1010 ohms
Dielectric Strength – (500 vac, rms [60
hz/sec])
volts/mil ASTM D149-92
880 volts/mil 600
Breakdown Voltage 1,760 volts 3,000 volts
Dielectric Constant (at 1 KHz)
ASTM D 150-92
3.40 4.06
Dissipation Factor 0.021 0.022
Tensile Lap Shear – Peak Load
ASTM D1002-72
(0.5 square inch on #6061 aluminum)
55 lbs.
Tensile Lap Shear – Peak Stress
ASTM D1002-72
109 PSI
Tensile Strength and Elongation
ASTM D2370-82
51 PSI
1915%
Thermal Conductivity
(ASTM C 518, results listed are at 109°F)
0.098 BTU-ft /ft2
-hr-F
0.17 watt/m-K
0.101 BTU-ft /ft2
-hr-F
0.18 watt/m-K
Coefficient of Thermal Expansion – first heat
ASTM D 696 – second heat
28 x 10-5 m/m/C
72 x 10-5 m/m/C
-6 x 10-5 m/m/C
92 x 10-5 m/m/C
SHELF LIFE AND STORAGE
Laminating adhesives should be used within 24 months from the manufacturing date and must
be stored at 70° F (21° C) and at 50% relative humidity.
RELATED LITERATURE
Refer to Product Bulletins of relevant foils and materials for product-specific handling,
production, and finishing information.
Page 6 of 6
CONTACT INFORMATION
For help with questions concerning Gerber products, please call your distributor or Gerber
Customer Service at 1-800-222-7446 or (860) 644-1551. Visit us on the Internet at
www.gerbertechnology.com/signage to learn more about our many other foils, materials and
equipment.
