ORAFOL ORACAL 975CA-070 Black Carbon Premium Structure Cast

Description

ORAFOL ORACAL 975CA-070 Black Carbon Premium Structure Cast
ORACAL® 975 PREMIUM STRUCTURE CAST
Description
5-6-mil, multi-layered cast PVC film with outstanding dimensional stability, optimum application characteristics, and a
textured surface. Available in 28 different colors and/or textures.
Release Liner
90# PE-coated silicone paper
Adhesive
Clear, solvent-based, repositionable, permanent adhesive
Area of Use
Specifically developed for exterior automotive accent restyling and interior applications for fine detailing.
Technical Data
Thickness (without liner and adhesive) 5-6-mil
Dimensional Stability (FINAT TM-14) Adhered to steel, no shrinkage in cross direction;
In length, <.004” Temperature Resistance Adhered to aluminum, -58°F to +230°F, no variation Fire Behavior (DIN 75200) Fire Rating Adhered to steel, self-extinguishing ASTM E 84-07 Class “A” Adhesive Power (FINAT TM-1, after 24 h, average) Adhered to stainless steel: 5.0 lb/in Tensile Strength (DIN EN ISO 527) Along: Min. 14 MPa Across: Min. 14 MPa Elongation at Break (DIN EN ISO 527) Along: Min. 70% Across: Min. 70% Seawaterability (DIN 50 021) Adhered to aluminum, after 100h/73°F, no variation Shelf Life (68°F/50% relative humidity) 2 years Minimum Life Expectancy (based on accepted application procedures on vertical surfaces) 5 years 3 years - metallic Minimum Application Temperature 46°F Available Lengths Available Widths 150’ (50-yard), 75’ (25-yard), 30’ (10-yard) 60”, 30” (not available in 50-yard)

To prevent damaging the surface during application, a soft or felt covered squeegee is recommended.
Note
Surfaces to which the material will be applied must be thoroughly cleaned from dust, grease or any contamination which could affect the
adhesion of the material. Freshly lacquered or painted surfaces should be completely cured. The compatibility of selected lacquers and
paints should be tested by the user, prior to application of the material. Films with structured surface are naturally more sensitive than the
unstructured. Accordingly, these films are to be treated carefully both in processing and in cleaning. Impurities affect the appearance of
structured films and require more frequent cleaning. Furthermore the application information published by ORAFOL is to be considered. The
batch traceability according to ISO 9001 is possible on the basis of the roll number.
IMPORTANT NOTICE
All ORACAL® products are subject to careful quality control throughout the manufacturing process and are warranted to be of merchantable
quality and free from manufacturing defects. Published information concerning ORACAL® products is based upon research which the
Company believes to be reliable although such information does not constitute a warranty. Because of the variety of uses of ORACAL®
products and the continuing development of new applications, the purchaser should carefully consider the suitability and performance of the
product for each intended use, and the purchaser shall assume all risks regarding such use.
All specifications are subject to change without prior notice.
WARNING: This product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm
070 Black sRGB: 47, 47, 47
